Follow these steps for proper installation:
1. Remove any magazine and ensure the rifle and workspace are clear of ammunition.
2. Press pivot and takedown pins; separate upper and lower receivers.
3. Loosen the pistol grip screw. In most cases, it is not necessary to completely remove the pistol grip.
4. Remove the installed safety.
5. Remove hammer pin. Remove the hammer and hammer spring assembly.
6. Remove the trigger pin. Remove the trigger, sear and trigger spring assembly.
7. Insert the Partisan Trigger cartridge assembly.
8. Install your Partisan Trigger 3-position safety. Partisan Trigger safeties must be used in conjunction with the trigger. It may be necessary to use a small tool to depress the safety detent to get the safety installed fully.
9. Tighten pistol grip screw.
10. Install anti-rotation pins and apply thread locker.
11. Place the rear lug of the upper receiver into the lower, and slightly pull back on the charging handle to enable the rear of the bolt carrier group to clear the out of battery safety sear.
12. Reinsert pivot and takedown pins.
13. Installation complete.

Magpul PMAG D-60 5.56 60RD

The PMAG D-60 is a durable, lightweight, highly reliable 60-round 5.56×45 NATO/.223 Remington* polymer drum magazine for AR15/M4 compatible weapons.

With a larger capacity than previous PMAGs, the PMAG D-60 gives the shooter 60 rounds of ammunition, effectively allowing the same round count as two standard capacity 30-round magazines without requiring a critical reload.

The unique drum configuration keeps the height of the magazine manageable as well as allowing for prone firing and easier storage. Features an easy-to-use loading lever, paint pen dot matrix for easy marking, and a rear window for instant capacity indication. Compatible with a wide range of NATO firearms such as the M4, M16, SCAR™ MK16/16S, HK®416, MR556, M27 IAR, IWI Tavor, and others.

Made in U.S.A.

FEATURES

• Next-generation impact and crush resistant polymer construction
• Wide compatibility with most ‘STANAG 4179’ platforms such as the AR15, M4, M16, SCAR MK16/16S, HK416, MR556, M27 IAR, IWI Tavor, and others
• Will seat fully loaded on a closed bolt
• Bolt hold open feature to lock the bolt back on the last round**
• Ratcheting Loading Lever to take tension off the spring for easy loading by hand
• Feed Tower compatible with most loading devices, including USGI stripper clips and guides, the StripLULA™, and others
• Designed to be left loaded for long term storage without any loss of function or degradation
• All components used are corrosion resistant
• Easy to disassemble for cleaning with only a flat-bladed screwdriver or similar
• Anti-glare translucent window on rear of drum allows for easy determination of rounds remaining
• Paint pen dot matrix panel on back of body to allow for identification marking
• Slip-on, semi-rigid Dust Cover prevents grit and debris intrusion during storage and transport

.
